STRIP05 – Y-Factor test_BIAS1100_up LB (PS1010-PWR0 blind)
General information
| Polarimeter | STRIP05 |
| Acquisition date | |
| Band | Q |
| Cryogenic? | Yes |
| Operators | Claudio Pincella |
| Description | Y-Factor test_BIAS1100_up LB (PS1010-PWR0 blind) |
| PHSW state | 1010 |
| Notes | The source data file was «SCI171215_170215 - STRIP05_Y-Factor_LA_20K_upLB_10-20-25-30-35-40-45-50_PS1010_bias1100_15Dec2017.txt» (2710 kB) BIAS 1100 ADU, more temperature steps. Detector offsets here indicated are not fully reliable |
| Author | claudio |
| Date of creation | |
| JSON record | Link |
- Download data file (517.4 KB)
HEMT biases
| HEMT | Vd [V] | Id [mA] | Vg [mV] |
|---|---|---|---|
| H0 (HA1) | 0.9 | 7.0 | 337.0 |
| H1 (HB1) | 0.9 | 6.7 | 323.0 |
| H2 (HA2) | 0.9 | 8.5 | 396.0 |
| H3 (HB2) | 0.9 | 8.8 | 333.0 |
| H4 (HA3) | 0.9 | 6.55 | 344.0 |
| H5 (HB3) | 0.9 | 8.6 | 194.0 |
Temperatures
| TA1 [K] | TA2 [K] | TB1 [K] | TB2 [K] | Tp1 [K] | Tp2 [K] | Tc1 [K] | Tc2 [K] | |
|---|---|---|---|---|---|---|---|---|
| 20.0 | 25.5 | 10.0 | 13.7 | 20.0 | 16.7 | 15.0 | 25.7 |
|
| 20.0 | 25.5 | 20.0 | 27.4 | 20.0 | 16.7 | 15.0 | 25.7 |
|
| 20.0 | 25.5 | 25.0 | 29.9 | 20.0 | 16.7 | 15.0 | 25.7 |
|
| 20.0 | 25.5 | 30.0 | 36.6 | 20.0 | 16.7 | 15.0 | 25.7 |
|
| 20.0 | 25.5 | 35.0 | 42.9 | 20.0 | 16.7 | 15.0 | 25.7 |
|
| 20.0 | 25.5 | 40.0 | 48.5 | 20.0 | 16.7 | 15.0 | 25.7 |
|
| 20.0 | 25.5 | 45.0 | 54.0 | 20.0 | 16.7 | 15.0 | 25.7 |
|
| 20.0 | 25.5 | 50.0 | 59.5 | 20.0 | 16.7 | 15.0 | 25.7 |
|
