STRIP63 – Bandpass characterization Tcryo (PS0110 - PWR0 blind)

General information

Edit  Delete

Polarimeter STRIP63
Acquisition date
BandQ
Cryogenic?Yes
OperatorsClaudio Pincella
DescriptionBandpass characterization Tcryo (PS0110 - PWR0 blind)
PHSW state0110
Notes

The source data file was «SCI170830_123919 - STRIP63_Tcryo20K_RF_-40dBm_0110_30Aug2017.txt» (394 kB)

Authorclaudio
Date of creation
JSON recordLink
ADC offsets
PWR0 PWR1 PWR2 PWR3
1884 1877 1842 1895 Edit  Delete
Detector outputs
PWR0 PWR1 PWR2 PWR3
78700 77930 78000 79790 Edit  Delete
HEMT biases
HEMT Vd [V] Id [mA] Vg [mV]
H0 (HA1) 0.91 3.0 276.0
H1 (HB1) 0.91 3.3 418.0
H2 (HA2) 1.21 13.0 221.0
H3 (HB2) 1.21 13.05 310.0
H4 (HA3) 0.91 8.1 283.0
H5 (HB3) 0.91 9.1 238.0
Temperatures

Reports

Noise temperatures
Bandpasses
Method Central frequency Bandwidth Details Report Actions
43.12±0.31 8.13±0.45 JSON Download Edit  Delete
Spectrum
