STRIP63 – Y-Factor test_down LB (PS0101-PWR0 blind)
General information
| Polarimeter | STRIP63 |
| Acquisition date | |
| Band | Q |
| Cryogenic? | Yes |
| Operators | Claudio Pincella |
| Description | Y-Factor test_down LB (PS0101-PWR0 blind) |
| PHSW state | 0101 |
| Notes | The source data file was «SCI170830_133808 - STRIP63_Y-Factor_LB_20K_down_50-40-30-20-10_PS0101_30Aug2017.txt» (1852 kB) |
| Author | claudio |
| Date of creation | |
| JSON record | Link |
- Download data file (359.1 KB)
HEMT biases
| HEMT | Vd [V] | Id [mA] | Vg [mV] |
|---|---|---|---|
| H0 (HA1) | 0.91 | 3.0 | 276.0 |
| H1 (HB1) | 0.91 | 3.3 | 418.0 |
| H2 (HA2) | 1.21 | 13.0 | 221.0 |
| H3 (HB2) | 1.21 | 13.05 | 310.0 |
| H4 (HA3) | 0.91 | 8.1 | 283.0 |
| H5 (HB3) | 0.91 | 9.1 | 238.0 |
Temperatures
| TA1 [K] | TA2 [K] | TB1 [K] | TB2 [K] | Tp1 [K] | Tp2 [K] | Tc1 [K] | Tc2 [K] | |
|---|---|---|---|---|---|---|---|---|
| 20.0 | 26.1 | 50.0 | 59.2 | 20.0 | 16.2 | 15.0 | 24.7 |
|
| 20.0 | 26.1 | 40.0 | 48.4 | 20.0 | 16.2 | 15.0 | 24.7 |
|
| 20.0 | 26.1 | 30.0 | 36.4 | 20.0 | 16.2 | 15.0 | 24.7 |
|
| 20.0 | 26.1 | 20.0 | 27.3 | 20.0 | 16.2 | 15.0 | 24.7 |
|
| 20.0 | 26.1 | 10.0 | 13.6 | 20.0 | 16.2 | 15.0 | 24.7 |
|
