Strip Test Database
STRIP57 – Y-Factor test_down LB (PS1001-PWR3 blind)
General information
| Polarimeter | STRIP57 |
| Acquisition date | |
| Band | Q |
| Cryogenic? | Yes |
| Operators | Claudio Pincella |
| Description | Y-Factor test_down LB (PS1001-PWR3 blind) |
| PHSW state | 1001 |
| Notes | The source data file was «SCI170606_134419 - STRIP57_Y-Factor_LB_50K_down_60-50-40-30-20-10_PS1001_06Jun2017.txt» (2296 kB) |
| Author | claudio |
| Date of creation | |
| JSON record | Link |
- Download data file (476.6 KB)
HEMT biases
| HEMT | Vd [V] | Id [mA] | Vg [mV] |
|---|---|---|---|
| H0 (HA1) | 0.9 | 4.95 | 82.0 |
| H1 (HB1) | 0.9 | 4.0 | 251.0 |
| H2 (HA2) | 1.21 | 15.9 | 383.0 |
| H3 (HB2) | 1.2 | 14.3 | -87.0 |
| H4 (HA3) | 0.9 | 11.0 | 159.0 |
| H5 (HB3) | 0.93 | 11.0 | 265.0 |
Temperatures
| TA1 [K] | TA2 [K] | TB1 [K] | TB2 [K] | Tp1 [K] | Tp2 [K] | Tc1 [K] | Tc2 [K] | |
|---|---|---|---|---|---|---|---|---|
| 20.0 | 24.9 | 60.0 | 61.2 | 20.0 | 16.9 | 15.0 | 25.0 |
|
| 20.0 | 25.0 | 50.0 | 52.0 | 20.0 | 16.9 | 15.0 | 25.0 |
|
| 20.0 | 25.0 | 40.0 | 41.9 | 20.0 | 16.9 | 15.0 | 25.0 |
|
| 20.0 | 25.0 | 30.0 | 31.7 | 20.0 | 16.9 | 15.0 | 25.0 |
|
| 20.0 | 25.0 | 20.0 | 23.3 | 20.0 | 16.9 | 15.0 | 25.0 |
|
| 20.0 | 25.0 | 10.0 | 12.6 | 20.0 | 16.9 | 15.0 | 25.0 |
|
