STRIP52 – Y-Factor test_down LB (PS0101-PWR0 blind)

General information

Edit  Delete

Polarimeter STRIP52
Acquisition date
BandQ
Cryogenic?Yes
OperatorsClaudio Pincella
DescriptionY-Factor test_down LB (PS0101-PWR0 blind)
PHSW state0101
Notes

The source data file was «SCI171109_110112 - STRIP52_Y-Factor_LB_40K_down_50-40-30-20-10_PS0101_09Nov2017.txt» (1912 kB)

Authorclaudio
Date of creation
JSON recordLink
ADC offsets
PWR0 PWR1 PWR2 PWR3
1905 1802 1846 1860 Edit  Delete
Detector outputs
PWR0 PWR1 PWR2 PWR3
81840 80130 79000 79970 Edit  Delete
HEMT biases
HEMT Vd [V] Id [mA] Vg [mV]
H0 (HA1) 0.9 5.0 -37.0
H1 (HB1) 0.89 2.56 -91.0
H2 (HA2) 1.2 15.27 208.0
H3 (HB2) 1.2 13.45 190.0
H4 (HA3) 0.9 10.0 100.0
H5 (HB3) 0.92 9.01 299.0
Temperatures
TA1 [K] TA2 [K] TB1 [K] TB2 [K] Tp1 [K] Tp2 [K] Tc1 [K] Tc2 [K]
20.0 25.6 50.0 59.5 20.0 16.6 15.0 25.5 Edit  Delete
20.0 25.6 40.0 48.3 20.0 16.6 15.0 25.5 Edit  Delete
20.0 25.6 30.0 36.5 20.0 16.6 15.0 25.5 Edit  Delete
20.0 25.6 20.0 27.3 20.0 16.6 15.0 25.5 Edit  Delete

Reports

Noise temperatures
Method Tnoise [K] GQ1 [ADU/K] GU1 [ADU/K] GU2 [ADU/K] GQ2 [ADU/K] Details Report Action
non-linear fit 30.6±1.0 1955±58 2362±42 2127±38 1706±42 JSON Download Edit  Delete
Bandpasses
Spectrum
