Strip Test Database
STRIP47 – Y-Factor test_down LA (PS0110-PWR0 blind)
General information
| Polarimeter | STRIP47 |
| Acquisition date | |
| Band | Q |
| Cryogenic? | Yes |
| Operators | Claudio Pincella |
| Description | Y-Factor test_down LA (PS0110-PWR0 blind) |
| PHSW state | 0110 |
| Notes | The source data file was «SCI170322_143312 - Y-Factor_20K down LA 40-30-20-10_Polar da caso 2 RF_PS0110_22March2017.txt» (1436 kB) |
| Author | claudio |
| Date of creation | |
| JSON record | Link |
- Download data file (298.0 KB)
HEMT biases
| HEMT | Vd [V] | Id [mA] | Vg [mV] |
|---|---|---|---|
| H0 (HA1) | 0.8 | 4.5 | 160.0 |
| H1 (HB1) | 0.9 | 6.7 | -140.0 |
| H2 (HA2) | 0.7 | 5.7 | 360.0 |
| H3 (HB2) | 0.9 | 7.1 | 385.0 |
| H4 (HA3) | 0.7 | 5.8 | 145.0 |
| H5 (HB3) | 0.7 | 7.2 | -140.0 |
Temperatures
| TA1 [K] | TA2 [K] | TB1 [K] | TB2 [K] | Tp1 [K] | Tp2 [K] | Tc1 [K] | Tc2 [K] | |
|---|---|---|---|---|---|---|---|---|
| 40.0 | 43.4 | 20.0 | 22.3 | 20.0 | 12.9 | 15.0 | 24.4 |
|
| 30.0 | 33.2 | 20.0 | 22.3 | 20.0 | 12.9 | 15.0 | 24.4 |
|
| 20.0 | 24.5 | 20.0 | 22.3 | 20.0 | 12.9 | 15.0 | 24.4 |
|
| 10.0 | 11.7 | 20.0 | 22.3 | 20.0 | 12.9 | 15.0 | 24.4 |
|
