Strip Test Database

STRIP67 – Bandpass characterization

General information

Edit  Delete

Polarimeter STRIP67
Acquisition date
BandQ
Cryogenic?Yes
OperatorsSilvia Caprioli, Mario Zannoni
PHSW state0110
Notes

The source data file was «SCI170705_135659 - STRIP67_Tcryo20K_RF_-40dBm_0110_pol-JPL_05Jul2017.txt» (408 kB)

Authorsilvia
Date of creation
JSON recordLink
ADC offsets
PWR0 PWR1 PWR2 PWR3
1928 1968 1980 2006 Edit  Delete
Detector outputs
PWR0 PWR1 PWR2 PWR3
58740 57100 60120 55640 Edit  Delete
HEMT biases
HEMT Vd [V] Id [mA] Vg [mV]
H0 (HA1) 0.9 4.45 360.0
H1 (HB1) 0.9 4.4 270.0
H2 (HA2) 1.21 13.95 -9.0
H3 (HB2) 1.21 15.01 42.0
H4 (HA3) 0.9 10.0 236.0
H5 (HB3) 0.9 8.1 295.0
Temperatures

Reports

Noise temperatures
Bandpasses
Method Central frequency Bandwidth Details Report Actions
43.44±0.14 8.75±0.41 JSON Download Edit  Delete
Spectrum
