STRIP67 – Long acquisition
General information
| Polarimeter | STRIP67 |
| Acquisition date | |
| Band | Q |
| Cryogenic? | Yes |
| Operators | Silvia Caprioli, Mario Zannoni |
| PHSW state | switching |
| Notes | The source data file was «SCI170705_111225 - STRIP67_1_f__PS-default_JPL polariz_05Jul2017.txt» (6333 kB) |
| Author | silvia |
| Date of creation | |
| JSON record | Link |
- Download data file (1.0 MB)
HEMT biases
| HEMT | Vd [V] | Id [mA] | Vg [mV] |
|---|---|---|---|
| H0 (HA1) | 0.9 | 4.45 | 360.0 |
| H1 (HB1) | 0.9 | 4.4 | 270.0 |
| H2 (HA2) | 1.21 | 13.95 | -9.0 |
| H3 (HB2) | 1.21 | 15.01 | 42.0 |
| H4 (HA3) | 0.9 | 10.0 | 236.0 |
| H5 (HB3) | 0.9 | 8.1 | 295.0 |
