STRIP12 – Long acquisition
General information
| Polarimeter | STRIP12 |
| Acquisition date | |
| Band | Q |
| Cryogenic? | Yes |
| Operators | Claudio Pincella |
| PHSW state | switching |
| Notes | The source data file was «SCI171026_131557 - STRIP12_1_f__PS-default_16hours_26Oct2017.txt» (95354 kB) |
| Author | claudio |
| Date of creation | |
| JSON record | Link |
- Download data file (14.9 MB)
HEMT biases
| HEMT | Vd [V] | Id [mA] | Vg [mV] |
|---|---|---|---|
| H0 (HA1) | 0.9 | 4.25 | 157.0 |
| H1 (HB1) | 0.9 | 8.2 | 60.0 |
| H2 (HA2) | 0.9 | 5.0 | 500.0 |
| H3 (HB2) | 0.9 | 8.5 | 500.0 |
| H4 (HA3) | 0.9 | 7.1 | 20.0 |
| H5 (HB3) | 0.9 | 10.6 | 420.0 |
