STRIP36 – Y-Factor test_up LB (PS0101-PWR0 blind)
General information
| Polarimeter | STRIP36 |
| Acquisition date | |
| Band | Q |
| Cryogenic? | Yes |
| Operators | Claudio Pincella |
| Description | Y-Factor test_up LB (PS0101-PWR0 blind) |
| PHSW state | 0101 |
| Notes | The source data file was «SCI170620_131059 - STRIP36_Y-Factor_LB_40K_up_10-20-30-40-50_PS0101_caso2_20Jun2017.txt» (1941 kB) |
| Author | claudio |
| Date of creation | |
| JSON record | Link |
- Download data file (397.7 KB)
HEMT biases
| HEMT | Vd [V] | Id [mA] | Vg [mV] |
|---|---|---|---|
| H0 (HA1) | 0.8 | 6.67 | 96.0 |
| H1 (HB1) | 0.8 | 6.86 | 61.0 |
| H2 (HA2) | 0.8 | 4.72 | 229.0 |
| H3 (HB2) | 0.8 | 5.51 | 237.0 |
| H4 (HA3) | 0.8 | 3.06 | 369.0 |
| H5 (HB3) | 0.8 | 4.48 | 0.0 |
Temperatures
| TA1 [K] | TA2 [K] | TB1 [K] | TB2 [K] | Tp1 [K] | Tp2 [K] | Tc1 [K] | Tc2 [K] | |
|---|---|---|---|---|---|---|---|---|
| 20.0 | 25.7 | 10.0 | 12.9 | 20.0 | 16.2 | 15.0 | 25.1 |
|
| 20.0 | 25.7 | 20.0 | 23.5 | 20.0 | 16.2 | 15.0 | 25.1 |
|
| 20.0 | 25.7 | 30.0 | 31.7 | 20.0 | 16.2 | 15.0 | 25.1 |
|
| 20.0 | 25.7 | 40.0 | 41.6 | 20.0 | 16.2 | 15.0 | 25.1 |
|
| 20.0 | 25.7 | 50.0 | 51.2 | 20.0 | 16.2 | 15.0 | 25.1 |
|
