STRIP27 – Bandpass characterization

General information

Edit  Delete

Polarimeter STRIP27
Acquisition date
BandQ
Cryogenic?Yes
OperatorsSilvia Caprioli, Claudio Pincella
PHSW state0110
Notes

The source data file was «SCI170413_125601 - Qband27_Tcryo20K_RF -40dBm_0110_PolarTamb_QUIET_13Apr2017.txt» (406 kB)

Authorsilvia
Date of creation
JSON recordLink
ADC offsets
PWR0 PWR1 PWR2 PWR3
1761 1784 1863 1893 Edit  Delete
Detector outputs
PWR0 PWR1 PWR2 PWR3
660 1160 2670 660 Edit  Delete
HEMT biases
HEMT Vd [V] Id [mA] Vg [mV]
H0 (HA1) 0.9 5.0 113.0
H1 (HB1) 0.9 4.2 270.0
H2 (HA2) 0.9 7.7 348.0
H3 (HB2) 0.9 8.9 495.0
H4 (HA3) 0.9 8.7 373.0
H5 (HB3) 0.9 9.0 485.0
Temperatures

Reports

Noise temperatures
Bandpasses
Method Central frequency Bandwidth Details Report Actions
43.57±0.06 7.15±0.12 JSON Download Edit  Delete
Spectrum
