STRIP34 – Bandpass characterization (PS0110 - PWR0 blind)

General information

Edit  Delete

Polarimeter STRIP34
Acquisition date
BandQ
Cryogenic?Yes
OperatorsClaudio Pincella
DescriptionBandpass characterization (PS0110 - PWR0 blind)
PHSW state0110
Notes

The source data file was «SCI171219_101701 - STRIP34_Tcryo20K_RF_-40dBm_0110_19Dec2017.txt» (478 kB)

Authorclaudio
Date of creation
JSON recordLink
ADC offsets
PWR0 PWR1 PWR2 PWR3
1840 1821 1816 1874 Edit  Delete
Detector outputs
PWR0 PWR1 PWR2 PWR3
97230 97220 96350 93400 Edit  Delete
HEMT biases
HEMT Vd [V] Id [mA] Vg [mV]
H0 (HA1) 0.9 8.61 117.0
H1 (HB1) 0.9 5.67 0.0
H2 (HA2) 0.9 9.76 504.0
H3 (HB2) 0.9 5.16 119.0
H4 (HA3) 0.9 11.9 157.0
H5 (HB3) 0.9 4.3 0.0
Temperatures

Reports

Noise temperatures
Bandpasses
Method Central frequency Bandwidth Details Report Actions
42.93±0.24 6.02±0.07 JSON Download Edit  Delete
Spectrum
