Strip Test Database
STRIP27 – Y-factor test
General information
| Polarimeter | STRIP27 |
| Acquisition date | |
| Band | Q |
| Cryogenic? | Yes |
| Operators | Silvia Caprioli, Claudio Pincella |
| PHSW state | 0110 |
| Notes | The source data file was «SCI170413_133619 - Qband27_Y-Factor_LB_20K_down_40-30-20-10_PS0110_caso1_QUIET_13Apr2017.txt» (1414 kB) |
| Author | silvia |
| Date of creation | |
| JSON record | Link |
- Download data file (288.9 KB)
HEMT biases
| HEMT | Vd [V] | Id [mA] | Vg [mV] |
|---|---|---|---|
| H0 (HA1) | 0.9 | 5.0 | 113.0 |
| H1 (HB1) | 0.9 | 4.2 | 270.0 |
| H2 (HA2) | 0.9 | 7.7 | 348.0 |
| H3 (HB2) | 0.9 | 8.9 | 495.0 |
| H4 (HA3) | 0.9 | 8.7 | 373.0 |
| H5 (HB3) | 0.9 | 9.0 | 485.0 |
Temperatures
| TA1 [K] | TA2 [K] | TB1 [K] | TB2 [K] | Tp1 [K] | Tp2 [K] | Tc1 [K] | Tc2 [K] | |
|---|---|---|---|---|---|---|---|---|
| 20.0 | 25.2 | 40.0 | 41.1 | 20.0 | 12.5 | 15.0 | 25.2 |
|
| 20.0 | 25.2 | 30.0 | 31.3 | 20.0 | 12.5 | 15.0 | 25.2 |
|
| 20.0 | 25.2 | 20.0 | 21.7 | 20.0 | 12.5 | 15.0 | 25.2 |
|
| 20.0 | 25.3 | 10.0 | 10.9 | 20.0 | 12.5 | 15.0 | 25.2 |
|
