STRIP30 – Bandpass characterization cryo (PS0110 - PWR0 blind)

General information

Edit  Delete

Polarimeter STRIP30
Acquisition date
BandQ
Cryogenic?Yes
OperatorsClaudio Pincella
DescriptionBandpass characterization cryo (PS0110 - PWR0 blind)
PHSW state0110
Notes

The source data file was «SCI170621_153813 - STRIP30_Tcryo20K_RF -40dBm_0110_pol_finali_newLB_21June2017.txt» (382 kB)

Authorclaudio
Date of creation
JSON recordLink
ADC offsets
PWR0 PWR1 PWR2 PWR3
1881 1820 1862 1883 Edit  Delete
Detector outputs
PWR0 PWR1 PWR2 PWR3
82250 84150 80895 83210 Edit  Delete
HEMT biases
HEMT Vd [V] Id [mA] Vg [mV]
H0 (HA1) 0.9 11.7 -180.0
H1 (HB1) 0.9 9.3 -105.0
H2 (HA2) 0.9 11.0 222.0
H3 (HB2) 0.9 11.0 326.0
H4 (HA3) 0.9 11.0 -98.0
H5 (HB3) 0.9 4.0 154.0
Temperatures

Reports

Noise temperatures
Bandpasses
Method Central frequency Bandwidth Details Report Actions
43.92±0.38 7.54±0.11 JSON Download Edit  Delete
Spectrum
