STRIP29 – Bandpass characterization cryo (PS0101 - PWR3 blind)

General information

Edit  Delete

Polarimeter STRIP29
Acquisition date
BandQ
Cryogenic?Yes
OperatorsClaudio Pincella
DescriptionBandpass characterization cryo (PS0101 - PWR3 blind)
PHSW state0101
Notes

The source data file was «SCI170419_142011 - STRIP29_Tcryo20K_RF -40dBm_0101_STRIP_Polar_base_19Apr2017.txt» (415 kB)

Authorclaudio
Date of creation
JSON recordLink
ADC offsets
PWR0 PWR1 PWR2 PWR3
1851 1865 1809 1889 Edit  Delete
Detector outputs
PWR0 PWR1 PWR2 PWR3
-125 -50 -2025 1610 Edit  Delete
HEMT biases
HEMT Vd [V] Id [mA] Vg [mV]
H0 (HA1) 0.6 6.5 251.0
H1 (HB1) 0.6 6.9 179.0
H2 (HA2) 0.6 5.5 376.0
H3 (HB2) 0.6 6.2 311.0
H4 (HA3) 0.6 6.4 0.0
H5 (HB3) 0.6 7.1 -187.0
Temperatures

Reports

Noise temperatures
Bandpasses
Method Central frequency Bandwidth Details Report Actions
43.28±0.26 7.08±0.25 JSON Download Edit  Delete
Spectrum
