STRIP29 – Y-Factor test_down LB (PS0101-PWR0 blind)
General information
| Polarimeter | STRIP29 |
| Acquisition date | |
| Band | Q |
| Cryogenic? | Yes |
| Operators | Claudio Pincella |
| Description | Y-Factor test_down LB (PS0101-PWR0 blind) |
| PHSW state | 0101 |
| Notes | The source data file was «SCI170419_145056 - STRIP29_Y-Factor_LB_20K_down_40-30-20_PS0101_STRIP_caso_base_19Apr2017.txt» (959 kB) |
| Author | claudio |
| Date of creation | |
| JSON record | Link |
- Download data file (186.7 KB)
HEMT biases
| HEMT | Vd [V] | Id [mA] | Vg [mV] |
|---|---|---|---|
| H0 (HA1) | 1.0 | 2.0 | 3.0 |
| H1 (HB1) | 4.0 | 5.0 | 6.0 |
| H2 (HA2) | 7.0 | 8.0 | 9.0 |
| H3 (HB2) | 10.0 | 11.0 | 12.0 |
| H4 (HA3) | 13.0 | 14.0 | 15.0 |
| H5 (HB3) | 16.0 | 17.0 | 18.0 |
Temperatures
| TA1 [K] | TA2 [K] | TB1 [K] | TB2 [K] | Tp1 [K] | Tp2 [K] | Tc1 [K] | Tc2 [K] | |
|---|---|---|---|---|---|---|---|---|
| 20.0 | 25.3 | 40.0 | 41.5 | 20.0 | 13.4 | 15.0 | 24.8 |
|
| 20.0 | 25.2 | 30.0 | 31.6 | 20.0 | 13.4 | 15.0 | 24.8 |
|
| 20.0 | 25.2 | 20.0 | 23.0 | 20.0 | 13.4 | 15.0 | 24.8 |
|
