STRIP17 – Y-Factor test_up LB (PS0101-PWR0 blind)
General information
| Polarimeter | STRIP17 |
| Acquisition date | |
| Band | Q |
| Cryogenic? | Yes |
| Operators | Claudio Pincella |
| Description | Y-Factor test_up LB (PS0101-PWR0 blind) |
| PHSW state | 0101 |
| Notes | The source data file was «SCI171031_133506 - STRIP17_Y-Factor_LB_20K_up_20-30-40-50_PS0101_31Oct2017.txt» (1798 kB) |
| Author | claudio |
| Date of creation | |
| JSON record | Link |
- Download data file (408.3 KB)
HEMT biases
| HEMT | Vd [V] | Id [mA] | Vg [mV] |
|---|---|---|---|
| H0 (HA1) | 0.9 | 9.0 | -84.0 |
| H1 (HB1) | 0.9 | 1.7 | 264.0 |
| H2 (HA2) | 0.9 | 4.43 | 480.0 |
| H3 (HB2) | 0.9 | 4.6 | 600.0 |
| H4 (HA3) | 0.9 | 8.0 | 98.0 |
| H5 (HB3) | 0.9 | 6.7 | 159.0 |
Temperatures
| TA1 [K] | TA2 [K] | TB1 [K] | TB2 [K] | Tp1 [K] | Tp2 [K] | Tc1 [K] | Tc2 [K] | |
|---|---|---|---|---|---|---|---|---|
| 20.0 | 25.7 | 20.0 | 27.4 | 20.0 | 16.7 | 15.0 | 25.1 |
|
| 20.0 | 25.7 | 30.0 | 36.5 | 20.0 | 16.7 | 15.0 | 25.1 |
|
| 20.0 | 25.7 | 40.0 | 48.4 | 20.0 | 16.7 | 15.0 | 25.1 |
|
| 20.0 | 25.7 | 50.0 | 59.5 | 20.0 | 16.7 | 15.0 | 25.1 |
|
