STRIP15 – Y-Factor test_up LB (PS0101-PWR0 blind)
General information
| Polarimeter | STRIP15 |
| Acquisition date | |
| Band | Q |
| Cryogenic? | Yes |
| Operators | Claudio Pincella |
| Description | Y-Factor test_up LB (PS0101-PWR0 blind) |
| PHSW state | 0101 |
| Notes | The source data file was «SCI170329_124940 - Qband15_Y-Factor_LB_30K up_10-20-30-40_Polar caso 4_PS0101_29March2017.txt» (1424 kB) |
| Author | claudio |
| Date of creation | |
| JSON record | Link |
- Download data file (277.9 KB)
HEMT biases
| HEMT | Vd [V] | Id [mA] | Vg [mV] |
|---|---|---|---|
| H0 (HA1) | 0.9 | 4.4 | -200.0 |
| H1 (HB1) | 0.9 | 4.6 | 210.0 |
| H2 (HA2) | 0.9 | 5.5 | 260.0 |
| H3 (HB2) | 0.9 | 9.5 | 440.0 |
| H4 (HA3) | 0.9 | 7.2 | 100.0 |
| H5 (HB3) | 0.9 | 7.4 | 77.0 |
Temperatures
| TA1 [K] | TA2 [K] | TB1 [K] | TB2 [K] | Tp1 [K] | Tp2 [K] | Tc1 [K] | Tc2 [K] | |
|---|---|---|---|---|---|---|---|---|
| 20.0 | 25.9 | 10.0 | 11.9 | 20.0 | 12.3 | 15.0 | 24.7 |
|
| 20.0 | 25.9 | 20.0 | 22.9 | 20.0 | 12.4 | 15.0 | 24.6 |
|
| 20.0 | 25.9 | 30.0 | 31.4 | 20.0 | 12.5 | 15.0 | 24.6 |
|
| 20.0 | 25.9 | 40.0 | 41.5 | 20.0 | 12.6 | 15.0 | 24.6 |
|
