STRIP12 – Y-Factor test_down LB (PS0110-PWR3 blind)

General information

Edit  Delete

Polarimeter STRIP12
Acquisition date
BandQ
Cryogenic?Yes
OperatorsClaudio Pincella
DescriptionY-Factor test_down LB (PS0110-PWR3 blind)
PHSW state0110
Notes

The source data file was «SCI171026_110455 - STRIP12_Y-Factor_LB_30K_down_50-40-30-20_PS0110_26Oct2017.txt» (1734 kB)

Authorclaudio
Date of creation
JSON recordLink
ADC offsets
PWR0 PWR1 PWR2 PWR3
1862 1846 1802 1807 Edit  Delete
Detector outputs
PWR0 PWR1 PWR2 PWR3
68700 67630 66400 69800 Edit  Delete
HEMT biases
HEMT Vd [V] Id [mA] Vg [mV]
H0 (HA1) 0.9 4.25 157.0
H1 (HB1) 0.9 8.2 60.0
H2 (HA2) 0.9 5.0 500.0
H3 (HB2) 0.9 8.5 500.0
H4 (HA3) 0.9 7.1 20.0
H5 (HB3) 0.9 10.6 420.0
Temperatures
TA1 [K] TA2 [K] TB1 [K] TB2 [K] Tp1 [K] Tp2 [K] Tc1 [K] Tc2 [K]
20.0 25.4 50.0 59.7 20.0 16.9 15.0 25.5 Edit  Delete
20.0 25.4 40.0 48.6 20.0 16.9 15.0 25.5 Edit  Delete
20.0 25.4 30.0 36.7 20.0 16.9 15.0 25.5 Edit  Delete
20.0 25.4 20.0 27.6 20.0 16.9 15.0 25.5 Edit  Delete

Reports

Noise temperatures
Method Tnoise [K] GQ1 [ADU/K] GU1 [ADU/K] GU2 [ADU/K] GQ2 [ADU/K] Details Report Action
non-linear fit 24.2±3.1 1068±81 1333±81 1219±74 939±92 JSON Download Edit  Delete
Bandpasses
Spectrum
