STRIP08 – Y-Factor test_down LA (PS0101-PWR3 blind)
General information
| Polarimeter | STRIP08 |
| Acquisition date | |
| Band | Q |
| Cryogenic? | Yes |
| Operators | Mario Zannoni |
| Description | Y-Factor test_down LA (PS0101-PWR3 blind) |
| PHSW state | 0101 |
| Notes | The source data file was «SCI170331_114126 - Qband08_20K_PS0101_vd06_idfoglio_31032017_Yfac_LA_40_30_20_10e5.txt» (955 kB) There are only three temperatures listed in this page, but the plot clearly shows four steps. The first step (10 K) was not recorded, apparently. Moreover, there are no detector offsets recorded in this page. How to analyze this test? |
| Author | claudio |
| Date of creation | |
| JSON record | Link |
- Download data file (212.2 KB)
ADC offsets
HEMT biases
| HEMT | Vd [V] | Id [mA] | Vg [mV] |
|---|---|---|---|
| H0 (HA1) | 0.7 | 4.3 | 600.0 |
| H1 (HB1) | 0.7 | 7.0 | 80.0 |
| H2 (HA2) | 0.7 | 7.4 | 260.0 |
| H3 (HB2) | 0.6 | 4.9 | 0.0 |
| H4 (HA3) | 0.7 | 7.0 | -380.0 |
| H5 (HB3) | 0.7 | 6.1 | -100.0 |
Temperatures
| TA1 [K] | TA2 [K] | TB1 [K] | TB2 [K] | Tp1 [K] | Tp2 [K] | Tc1 [K] | Tc2 [K] | |
|---|---|---|---|---|---|---|---|---|
| 40.0 | 44.2 | 20.0 | 22.9 | 20.0 | 12.4 | 15.0 | 24.6 |
|
| 30.0 | 33.8 | 20.0 | 22.9 | 20.0 | 12.4 | 15.0 | 24.6 |
|
| 20.0 | 25.9 | 20.0 | 22.9 | 20.0 | 12.4 | 15.0 | 24.6 |
|
