Strip Test Database
STRIP08 – Y-Factor test_down LB (PS0101-PWR0 blind)
General information
| Polarimeter | STRIP08 |
| Acquisition date | |
| Band | Q |
| Cryogenic? | Yes |
| Operators | Mario Zannoni |
| Description | Y-Factor test_down LB (PS0101-PWR0 blind) |
| PHSW state | 0101 |
| Notes | The source data file was «SCI170331_120117 - Qband08_20K_PS0101_vd06_idfoglio_31032017_Yfac_LB_40_30_20_10.txt» (1112 kB) As for test 276, there is not enough data about the temperatures of the input loads, nor detector offsets have been recorded. |
| Author | claudio |
| Date of creation | |
| JSON record | Link |
- Download data file (218.2 KB)
ADC offsets
HEMT biases
| HEMT | Vd [V] | Id [mA] | Vg [mV] |
|---|---|---|---|
| H0 (HA1) | 0.7 | 4.3 | 600.0 |
| H1 (HB1) | 0.7 | 7.0 | 80.0 |
| H2 (HA2) | 0.7 | 7.4 | 260.0 |
| H3 (HB2) | 0.6 | 4.9 | 0.0 |
| H4 (HA3) | 0.7 | 7.0 | -380.0 |
| H5 (HB3) | 0.7 | 6.1 | -100.0 |
Temperatures
| TA1 [K] | TA2 [K] | TB1 [K] | TB2 [K] | Tp1 [K] | Tp2 [K] | Tc1 [K] | Tc2 [K] | |
|---|---|---|---|---|---|---|---|---|
| 20.0 | 25.9 | 40.0 | 41.5 | 20.0 | 12.4 | 15.0 | 24.6 |
|
| 20.0 | 25.9 | 30.0 | 31.4 | 20.0 | 12.4 | 15.0 | 24.6 |
|
| 20.0 | 25.9 | 20.0 | 22.9 | 20.0 | 12.4 | 15.0 | 24.6 |
|
