Strip Test Database
STRIP30 – Bandpass characterization Tambient (PS0110 - PWR0 blind)
General information
| Polarimeter | STRIP30 |
| Acquisition date | |
| Band | Q |
| Cryogenic? | No |
| Operators | Claudio Pincella |
| Description | Bandpass characterization Tambient (PS0110 - PWR0 blind) |
| PHSW state | 0110 |
| Notes | The source data file was «SCI170119_200826 - Qband30_Tamb_RF -15dBm_0110_aumento i pari di 0.1V su H0-2_19January17.txt» (382 kB) |
| Author | claudio |
| Date of creation | |
| JSON record | Link |
- Download data file (81.4 KB)
ADC offsets
Detector outputs
HEMT biases
| HEMT | Vd [V] | Id [mA] | Vg [mV] |
|---|---|---|---|
| H0 (HA1) | 0.7 | 7.23 | -385.0 |
| H1 (HB1) | 0.6 | 6.03 | -280.0 |
| H2 (HA2) | 0.7 | 6.69 | 0.0 |
| H3 (HB2) | 0.6 | 6.14 | 100.0 |
| H4 (HA3) | 0.7 | 7.8 | 58.0 |
| H5 (HB3) | 0.7 | 4.76 | 20.0 |
