Strip Test Database
STRIP54 – Bandpass characterization Tambient (PS0101 - PWR3 blind)
General information
| Polarimeter | STRIP54 |
| Acquisition date | |
| Band | Q |
| Cryogenic? | No |
| Operators | Claudio Pincella |
| Description | Bandpass characterization Tambient (PS0101 - PWR3 blind) |
| PHSW state | 0101 |
| Notes | The source data file was «SCI170209_231722 - Quiet02_Tamb_RF -10dBm_0101_base case with equal total Tr_09February17.txt» (358 kB) |
| Author | claudio |
| Date of creation | |
| JSON record | Link |
- Download data file (74.7 KB)
ADC offsets
Detector outputs
HEMT biases
| HEMT | Vd [V] | Id [mA] | Vg [mV] |
|---|---|---|---|
| H0 (HA1) | 0.7 | 7.6 | -20.0 |
| H1 (HB1) | 0.7 | 7.8 | 100.0 |
| H2 (HA2) | 0.7 | 7.4 | -100.0 |
| H3 (HB2) | 0.7 | 7.6 | 120.0 |
| H4 (HA3) | 0.7 | 7.7 | 260.0 |
| H5 (HB3) | 0.7 | 7.5 | 260.0 |
