STRIP02 – Y-factor test

General information

Edit  Delete

Polarimeter STRIP02
Acquisition date
BandQ
Cryogenic?Yes
OperatorsPaola Battaglia, Claudio Pincella
PHSW state0110
Notes

The source data file was «SCI171011_130849 - STRIP02_Y-Factor_LA_20K_down_50-40-30-20_PS0110_11Oct2017.txt» (1926 kB)

Authorsilvia
Date of creation
JSON recordLink
ADC offsets
PWR0 PWR1 PWR2 PWR3
1837 1751 1796 1824 Edit  Delete
Detector outputs
PWR0 PWR1 PWR2 PWR3
86900 88780 89760 89120 Edit  Delete
HEMT biases
HEMT Vd [V] Id [mA] Vg [mV]
H0 (HA1) 0.9 4.0 220.0
H1 (HB1) 0.9 4.0 300.0
H2 (HA2) 0.9 6.0 256.0
H3 (HB2) 0.9 4.5 267.0
H4 (HA3) 0.9 6.0 123.0
H5 (HB3) 0.9 3.4 204.0
Temperatures
TA1 [K] TA2 [K] TB1 [K] TB2 [K] Tp1 [K] Tp2 [K] Tc1 [K] Tc2 [K]
20.0 26.0 50.0 59.8 20.0 16.6 15.0 24.7 Edit  Delete
20.0 26.0 40.0 48.7 20.0 16.6 15.0 24.7 Edit  Delete
20.0 26.0 30.0 36.9 20.0 16.6 15.0 24.7 Edit  Delete
20.0 26.0 20.0 27.8 20.0 16.6 15.0 24.7 Edit  Delete

Reports

Noise temperatures
Method Tnoise [K] GQ1 [ADU/K] GU1 [ADU/K] GU2 [ADU/K] GQ2 [ADU/K] Details Report Action
non-linear fit 32.0±0.8 324±6 355±5 347±5 281±6 JSON Download Edit  Delete
Bandpasses
Spectrum
