STRIP35 – Y-factor test

General information

Edit  Delete

Polarimeter STRIP35
Acquisition date
BandQ
Cryogenic?Yes
OperatorsPaola Battaglia, Claudio Pincella
PHSW state0101
Notes

BE CAREFUL:
In Y-factor test the information on temperatures for step 10K and 50K is missing

The source data file was «SCI171122_110728 - STRIP35_Y-Factor_LA_20K_upLB_10-20-30-40-50_PS0101_22Nov2017.txt» (2841 kB)

Authorsilvia
Date of creation
JSON recordLink
ADC offsets
PWR0 PWR1 PWR2 PWR3
1802 1788 1812 1799 Edit  Delete
Detector outputs
PWR0 PWR1 PWR2 PWR3
121050 118920 117950 122830 Edit  Delete
HEMT biases
HEMT Vd [V] Id [mA] Vg [mV]
H0 (HA1) 0.9 6.15 148.0
H1 (HB1) 0.9 5.9 48.0
H2 (HA2) 0.9 5.9 461.0
H3 (HB2) 0.9 2.0 362.0
H4 (HA3) 0.9 9.34 -200.0
H5 (HB3) 0.9 6.87 202.0
Temperatures
TA1 [K] TA2 [K] TB1 [K] TB2 [K] Tp1 [K] Tp2 [K] Tc1 [K] Tc2 [K]
20.0 26.4 20.0 27.6 20.0 16.6 15.0 24.8 Edit  Delete
20.0 26.4 30.0 36.6 20.0 16.6 15.0 24.8 Edit  Delete
20.0 26.4 40.0 48.6 20.0 16.6 15.0 24.8 Edit  Delete

Reports

Noise temperatures
Method Tnoise [K] GQ1 [ADU/K] GU1 [ADU/K] GU2 [ADU/K] GQ2 [ADU/K] Details Report Action
non-linear fit 24.9±8.9 727±161 1313±238 884±156 703±146 JSON Download Edit  Delete
