STRIP61 – Bandpass characterization

General information

Edit  Delete

Polarimeter STRIP61
Acquisition date
BandQ
Cryogenic?Yes
OperatorsPaola Battaglia, Mario Zannoni
PHSW state0110
Notes

The source data file was «SCI170711_150106 - STRIP61_Tcryo20K_RF_-40dBm_0110_full_JPL_11Jul2017.txt» (410 kB)

Authorsilvia
Date of creation
JSON recordLink
ADC offsets
PWR0 PWR1 PWR2 PWR3
1916 1885 1880 1811 Edit  Delete
Detector outputs
PWR0 PWR1 PWR2 PWR3
57400 59700 59800 60900 Edit  Delete
HEMT biases
HEMT Vd [V] Id [mA] Vg [mV]
H0 (HA1) 0.9 3.02 185.0
H1 (HB1) 0.9 3.1 341.0
H2 (HA2) 1.21 9.94 428.0
H3 (HB2) 1.21 12.01 504.0
H4 (HA3) 0.95 6.94 453.0
H5 (HB3) 0.92 8.03 181.0
Temperatures

Reports

Noise temperatures
Bandpasses
Method Central frequency Bandwidth Details Report Actions
43.23±0.20 7.92±0.64 JSON Download Edit  Delete
Spectrum
