STRIP68 – Bandpass characterization

General information

Edit  Delete

Polarimeter STRIP68
Acquisition date
BandQ
Cryogenic?Yes
OperatorsPaola Battaglia, Mario Zannoni
PHSW state0110
Notes

The source data file was «SCI170703_120406 - STRIP68_Tcryo20K_RF_-40dBm_0110_pol-JPL_03Jul2017.txt» (383 kB)

Authorsilvia
Date of creation
JSON recordLink
ADC offsets
PWR0 PWR1 PWR2 PWR3
1990 1937 1968 1890 Edit  Delete
Detector outputs
PWR0 PWR1 PWR2 PWR3
87700 85200 87400 88000 Edit  Delete
HEMT biases
HEMT Vd [V] Id [mA] Vg [mV]
H0 (HA1) 0.91 3.16 307.0
H1 (HB1) 0.91 3.16 331.0
H2 (HA2) 1.21 12.16 9.0
H3 (HB2) 1.21 11.08 -56.0
H4 (HA3) 0.91 9.3 245.0
H5 (HB3) 0.93 8.4 374.0
Temperatures

Reports

Noise temperatures
Bandpasses
Method Central frequency Bandwidth Details Report Actions
43.07±0.23 7.82±0.27 JSON Download Edit  Delete
Spectrum
