STRIP21 – Y-factor test

General information

Edit  Delete

Polarimeter STRIP21
Acquisition date
BandQ
Cryogenic?Yes
OperatorsClaudio Pincella
PHSW state0101
Notes

The source data file was «SCI171024_141234 - STRIP21_Y-Factor_LB_20K_up_20-30-40_PS0101_24Oct2017.txt» (1330 kB)

Authorsilvia
Date of creation
JSON recordLink
ADC offsets
PWR0 PWR1 PWR2 PWR3
1866 1819 1795 1879 Edit  Delete
Detector outputs
PWR0 PWR1 PWR2 PWR3
84670 84350 86370 85940 Edit  Delete
HEMT biases
HEMT Vd [V] Id [mA] Vg [mV]
H0 (HA1) 0.9 12.0 -121.0
H1 (HB1) 0.9 2.8 -352.0
H2 (HA2) 0.9 10.0 282.0
H3 (HB2) 0.9 2.8 -41.0
H4 (HA3) 0.9 10.0 -28.0
H5 (HB3) 0.9 8.0 76.0
Temperatures
TA1 [K] TA2 [K] TB1 [K] TB2 [K] Tp1 [K] Tp2 [K] Tc1 [K] Tc2 [K]
20.0 25.5 20.0 27.3 20.0 16.4 15.0 25.2 Edit  Delete
20.0 25.5 30.0 36.4 20.0 16.4 15.0 25.2 Edit  Delete
20.0 25.5 40.0 48.3 20.0 16.4 15.0 25.2 Edit  Delete

Reports

Noise temperatures
Method Tnoise [K] GQ1 [ADU/K] GU1 [ADU/K] GU2 [ADU/K] GQ2 [ADU/K] Details Report Action
non-linear fit 92.7±16.8 69±14 74±10 64±9 63±12 JSON Download Edit  Delete
Bandpasses
Spectrum
