STRIP09 – Bandpass characterization Tcryo (PS0110 - PWR0 blind)

General information

Edit  Delete

Polarimeter STRIP09
Acquisition date
BandQ
Cryogenic?Yes
OperatorsClaudio Pincella
DescriptionBandpass characterization Tcryo (PS0110 - PWR0 blind)
PHSW state0110
Notes

The source data file was «SCI180115_115245 - STRIP09_Tcryo20K_RF_-40dBm_0110_15Jan2018.txt» (454 kB)

High noise on detector PWR3, with difficulties to evaluate the results involving this detector

Authorclaudio
Date of creation
JSON recordLink
ADC offsets
PWR0 PWR1 PWR2 PWR3
1778 1857 1665 1798 Edit  Delete
Detector outputs
PWR0 PWR1 PWR2 PWR3
94800 96400 97350 96000 Edit  Delete
HEMT biases
HEMT Vd [V] Id [mA] Vg [mV]
H0 (HA1) 0.9 6.2 100.0
H1 (HB1) 0.9 9.85 280.0
H2 (HA2) 0.9 5.5 180.0
H3 (HB2) 0.9 8.0 600.0
H4 (HA3) 0.9 8.1 140.0
H5 (HB3) 0.9 7.9 120.0
Temperatures

Reports

Noise temperatures
Bandpasses
Method Central frequency Bandwidth Details Report Actions
43.23±0.12 6.41±0.50 JSON Download Edit  Delete
Spectrum
