STRIP09 – Y-Factor test_down LB (PS0110-PWR3 blind)
General information
| Polarimeter | STRIP09 |
| Acquisition date | |
| Band | Q |
| Cryogenic? | Yes |
| Operators | Claudio Pincella |
| Description | Y-Factor test_down LB (PS0110-PWR3 blind) |
| PHSW state | 0110 |
| Notes | The source data file was «SCI180115_154900 - STRIP09_Y-Factor__downLB-40K_50-45-40-35-30-25-20-15-10_PS0110_bis_15Jan2018.txt» (3195 kB) High noise on detector PWR3, with difficulties to evaluate the results involving this detector |
| Author | claudio |
| Date of creation | |
| JSON record | Link |
- Download data file (696.0 KB)
HEMT biases
| HEMT | Vd [V] | Id [mA] | Vg [mV] |
|---|---|---|---|
| H0 (HA1) | 0.9 | 6.2 | 100.0 |
| H1 (HB1) | 0.9 | 9.85 | 280.0 |
| H2 (HA2) | 0.9 | 5.5 | 180.0 |
| H3 (HB2) | 0.9 | 8.0 | 600.0 |
| H4 (HA3) | 0.9 | 8.1 | 140.0 |
| H5 (HB3) | 0.9 | 7.9 | 120.0 |
Temperatures
| TA1 [K] | TA2 [K] | TB1 [K] | TB2 [K] | Tp1 [K] | Tp2 [K] | Tc1 [K] | Tc2 [K] | |
|---|---|---|---|---|---|---|---|---|
| 20.0 | 26.0 | 50.0 | 59.7 | 15.0 | 25.7 | 20.0 | 16.2 |
|
| 20.0 | 26.0 | 45.0 | 54.5 | 15.0 | 25.7 | 20.0 | 16.2 |
|
| 20.0 | 26.0 | 40.0 | 48.9 | 15.0 | 25.7 | 20.0 | 16.2 |
|
| 20.0 | 26.0 | 35.0 | 43.3 | 15.0 | 25.7 | 20.0 | 16.2 |
|
| 20.0 | 26.0 | 30.0 | 36.7 | 15.0 | 25.7 | 20.0 | 16.2 |
|
| 20.0 | 26.0 | 25.0 | 29.9 | 15.0 | 25.7 | 20.0 | 16.2 |
|
| 20.0 | 26.0 | 20.0 | 27.4 | 15.0 | 25.7 | 20.0 | 16.2 |
|
| 20.0 | 26.0 | 15.0 | 25.0 | 15.0 | 25.7 | 20.0 | 16.2 |
|
