STRIP26 – Long acquisition

General information

Edit  Delete

Polarimeter STRIP26
Acquisition date
BandQ
Cryogenic?Yes
OperatorsClaudio Pincella
PHSW stateswitching
Notes

The source data file was «SCI180130_165637 - STRIP26_1_f__PS-default_18hours_30Jan2018.txt» (98855 kB)

Authorclaudio
Date of creation
JSON recordLink
ADC offsets
PWR0 PWR1 PWR2 PWR3
1784 1751 1757 1891 Edit  Delete
Detector outputs
PWR0 PWR1 PWR2 PWR3
194300 102900 112500 110200 Edit  Delete
HEMT biases
HEMT Vd [V] Id [mA] Vg [mV]
H0 (HA1) 0.6 4.6 198.0
H1 (HB1) 0.9 5.7 240.0
H2 (HA2) 0.7 7.61 -220.0
H3 (HB2) 0.7 9.2 -272.0
H4 (HA3) 0.7 7.0 218.0
H5 (HB3) 0.9 6.4 210.0
Temperatures
TA1 [K] TA2 [K] TB1 [K] TB2 [K] Tp1 [K] Tp2 [K] Tc1 [K] Tc2 [K]
20.0 26.0 20.0 27.4 20.0 15.8 15.0 25.3 Edit  Delete

Reports

Noise temperatures
Bandpasses
Spectrum
Method αI αQ fkQ [mHz] WNQ [mK2/Hz] αU fkU [mHz] WNU [mK2/Hz] Details Report Actions
1.11260±0.00000 1.280±0.020 2.0±2.0 8.00±2.000 1.010±0.030 4.0±5.0 4.00±1.000 JSON Download Edit  Delete
