Strip Test Database
STRIP26 – Y-Factor test_up LB (PS1010-PWR0 blind)
General information
| Polarimeter | STRIP26 |
| Acquisition date | |
| Band | Q |
| Cryogenic? | Yes |
| Operators | Claudio Pincella |
| Description | Y-Factor test_up LB (PS1010-PWR0 blind) |
| PHSW state | 1010 |
| Notes | The source data file was «SCI180130_161005 - STRIP26_Y-Factor__upLB-30K_10-20-30-40_PS1010_V5_30Jan2018.txt» (1331 kB) Results should be in general considered with caution, because the legs are strongly unbalanced, especially the ones relevant to the detectors that should be “blind” |
| Author | claudio |
| Date of creation | |
| JSON record | Link |
- Download data file (267.0 KB)
HEMT biases
| HEMT | Vd [V] | Id [mA] | Vg [mV] |
|---|---|---|---|
| H0 (HA1) | 0.6 | 4.6 | 198.0 |
| H1 (HB1) | 0.9 | 5.7 | 240.0 |
| H2 (HA2) | 0.7 | 7.61 | -220.0 |
| H3 (HB2) | 0.7 | 9.2 | -272.0 |
| H4 (HA3) | 0.7 | 7.0 | 218.0 |
| H5 (HB3) | 0.9 | 6.4 | 210.0 |
Temperatures
| TA1 [K] | TA2 [K] | TB1 [K] | TB2 [K] | Tp1 [K] | Tp2 [K] | Tc1 [K] | Tc2 [K] | |
|---|---|---|---|---|---|---|---|---|
| 20.0 | 26.0 | 10.0 | 13.6 | 20.0 | 15.8 | 15.0 | 25.3 |
|
| 20.0 | 26.0 | 20.0 | 27.4 | 20.0 | 15.8 | 15.0 | 25.3 |
|
| 20.0 | 26.0 | 30.0 | 36.6 | 20.0 | 15.8 | 15.0 | 25.3 |
|
| 20.0 | 26.0 | 40.0 | 48.6 | 20.0 | 15.8 | 15.0 | 25.3 |
|
