STRIP46 – Long acquisition
General information
| Polarimeter | STRIP46 |
| Acquisition date | |
| Band | Q |
| Cryogenic? | Yes |
| Operators | Claudio Pincella |
| PHSW state | switching |
| Notes | The source data file was «SCI180207_155853 - STRIP46_1_f_PS-default_pol-V1_24h_07Feb2018.txt» (138919 kB) |
| Author | silvia |
| Date of creation | |
| JSON record | Link |
- Download data file (19.8 MB)
HEMT biases
| HEMT | Vd [V] | Id [mA] | Vg [mV] |
|---|---|---|---|
| H0 (HA1) | 0.9 | 7.7 | 314.0 |
| H1 (HB1) | 0.9 | 10.47 | 56.0 |
| H2 (HA2) | 0.9 | 6.1 | 215.0 |
| H3 (HB2) | 0.9 | 4.0 | 100.0 |
| H4 (HA3) | 0.9 | 10.54 | 240.0 |
| H5 (HB3) | 0.9 | 10.88 | -40.0 |
