STRIP13 – Y-Factor test_up LB (PS0110-PWR3 blind)
General information
| Polarimeter | STRIP13 |
| Acquisition date | |
| Band | Q |
| Cryogenic? | Yes |
| Operators | Claudio Pincella |
| Description | Y-Factor test_up LB (PS0110-PWR3 blind) |
| PHSW state | 0110 |
| Notes | The source data file was «SCI180227_155220 - STRIP13_Y-Factor__upLB-40K_10-20-30-40-50_PS0110_V2_27Feb2018.txt» (1785 kB) |
| Author | claudio |
| Date of creation | |
| JSON record | Link |
- Download data file (372.7 KB)
HEMT biases
| HEMT | Vd [V] | Id [mA] | Vg [mV] |
|---|---|---|---|
| H0 (HA1) | 1.0 | 5.18 | -233.0 |
| H1 (HB1) | 1.0 | 3.62 | 579.0 |
| H2 (HA2) | 0.9 | 6.31 | 506.0 |
| H3 (HB2) | 0.9 | 14.11 | 460.0 |
| H4 (HA3) | 0.3 | 20.7 | 289.0 |
| H5 (HB3) | 0.9 | 17.43 | 368.0 |
Temperatures
| TA1 [K] | TA2 [K] | TB1 [K] | TB2 [K] | Tp1 [K] | Tp2 [K] | Tc1 [K] | Tc2 [K] | |
|---|---|---|---|---|---|---|---|---|
| 20.0 | 25.6 | 10.0 | 14.4 | 20.0 | 15.8 | 15.0 | 25.3 |
|
| 20.0 | 25.6 | 20.0 | 27.9 | 20.0 | 15.8 | 15.0 | 25.3 |
|
| 20.0 | 25.6 | 30.0 | 36.9 | 20.0 | 15.8 | 15.0 | 25.3 |
|
| 20.0 | 25.6 | 40.0 | 48.7 | 20.0 | 15.8 | 15.0 | 25.3 |
|
| 20.0 | 25.6 | 50.0 | 59.8 | 20.0 | 15.8 | 15.0 | 25.3 |
|
