Strip Test Database
STRIP65 – Y-Factor test_down LB (PS0110-PWR3 blind)
General information
| Polarimeter | STRIP65 |
| Acquisition date | |
| Band | Q |
| Cryogenic? | Yes |
| Operators | Paola Battaglia |
| Description | Y-Factor test_down LB (PS0110-PWR3 blind) |
| PHSW state | 0110 |
| Notes | The source data file was «SCI171107_162255 - STRIP65_Y-Factor_LA_20K_down_50-40-30-20-10_PS0110_07Nov2017.txt» (2353 kB) |
| Author | claudio |
| Date of creation | |
| JSON record | Link |
- Download data file (514.3 KB)
HEMT biases
| HEMT | Vd [V] | Id [mA] | Vg [mV] |
|---|---|---|---|
| H0 (HA1) | 0.9 | 3.05 | 163.0 |
| H1 (HB1) | 0.9 | 3.02 | 164.0 |
| H2 (HA2) | 0.9 | 12.1 | 261.0 |
| H3 (HB2) | 0.9 | 12.01 | 435.0 |
| H4 (HA3) | 0.9 | 8.07 | 220.0 |
| H5 (HB3) | 0.9 | 8.03 | 183.0 |
Temperatures
| TA1 [K] | TA2 [K] | TB1 [K] | TB2 [K] | Tp1 [K] | Tp2 [K] | Tc1 [K] | Tc2 [K] | |
|---|---|---|---|---|---|---|---|---|
| 20.0 | 25.5 | 50.0 | 59.7 | 20.0 | 16.1 | 14.9 | 24.8 |
|
| 20.0 | 25.5 | 40.0 | 48.6 | 20.0 | 16.1 | 14.9 | 24.8 |
|
| 20.0 | 25.5 | 30.0 | 36.6 | 20.0 | 16.1 | 14.9 | 24.8 |
|
| 20.0 | 25.5 | 20.0 | 27.5 | 20.0 | 16.1 | 14.9 | 24.8 |
|
| 20.0 | 25.5 | 10.0 | 13.7 | 20.0 | 16.1 | 14.9 | 24.8 |
|
