STRIP76 – Long acquisition

General information

Edit  Delete

Polarimeter STRIP76
Acquisition date
BandW
Cryogenic?Yes
OperatorsClaudio Pincella
PHSW stateswitching
Notes

The source data file was «SCI180420_150244 - STRIP_W58_1_f__PS-default_Polariz-US_24hours_20Apr2018.txt» (144135 kB)

Authorf.benedini
Date of creation
JSON recordLink
ADC offsets
PWR0 PWR1 PWR2 PWR3
1951 1884 1949 2004 Edit  Delete
Detector outputs
PWR0 PWR1 PWR2 PWR3
100000 103630 102410 100800 Edit  Delete
HEMT biases
HEMT Vd [V] Id [mA] Vg [mV]
H0 (HA1) 0.466 5.03 89.0
H1 (HB1) 0.466 5.06 276.0
H2 (HA2) 0.381 6.12 355.0
H3 (HB2) 0.361 4.97 222.0
H4 (HA3) 0.381 6.12 252.0
H5 (HB3) 0.361 4.97 135.0
Temperatures
TA1 [K] TA2 [K] TB1 [K] TB2 [K] Tp1 [K] Tp2 [K] Tc1 [K] Tc2 [K]
20.0 17.4 20.0 14.9 24.0 20.0 20.0 27.2 Edit  Delete

Reports

Noise temperatures
Bandpasses
Spectrum
Method αI αQ fkQ [mHz] WNQ [mK2/Hz] αU fkU [mHz] WNU [mK2/Hz] Details Report Actions
0.92606±0.00000 0.640±0.002 7.0±2.0 230.00±30.000 1.178±0.001 46.0±5.0 5.00±0.600 JSON Download Edit  Delete
