STRIP76 – Bandpass characterization - PS 0101

General information

Edit  Delete

Polarimeter STRIP76
Acquisition date
BandW
Cryogenic?Yes
OperatorsClaudio Pincella
DescriptionBandpass characterization - PS 0101
PHSW state0101
Notes

The source data file was «SCI180420_103425 - Wband58_Tcryo_RF-1dBm_0101_doppio-attenuatore_20Apr2018.txt» (912 kB)

Authorf.benedini
Date of creation
JSON recordLink
ADC offsets
PWR0 PWR1 PWR2 PWR3
1951 1884 1949 2004 Edit  Delete
Detector outputs
PWR0 PWR1 PWR2 PWR3
99480 102830 100620 100780 Edit  Delete
HEMT biases
HEMT Vd [V] Id [mA] Vg [mV]
H0 (HA1) 0.466 5.01 94.0
H1 (HB1) 0.466 5.06 285.0
H2 (HA2) 0.381 6.1 358.0
H3 (HB2) 0.361 4.86 219.0
H4 (HA3) 0.381 6.1 254.0
H5 (HB3) 0.361 4.86 138.0
Temperatures

Reports

Noise temperatures
Bandpasses
Method Central frequency Bandwidth Details Report Actions
97.36±0.20 7.10±1.05 JSON Download Edit  Delete
Spectrum
