STRIP76 – Y-factor - PS 0101 up

General information

Edit  Delete

Polarimeter STRIP76
Acquisition date
BandW
Cryogenic?Yes
OperatorsClaudio Pincella
DescriptionY-factor - PS 0101 up
PHSW state0101
Notes

The source data file was «SCI180420_123733 - STRIP_W58_Y-Factor_LB__up_20-30-40-50K_PS0101_20Apr2018.txt» (1341 kB)

Offset at P=0 are the ones at 14.00

Authorf.benedini
Date of creation
JSON recordLink
ADC offsets
PWR0 PWR1 PWR2 PWR3
1951 1884 1949 2004 Edit  Delete
Detector outputs
PWR0 PWR1 PWR2 PWR3
98900 103500 102040 101640 Edit  Delete
HEMT biases
HEMT Vd [V] Id [mA] Vg [mV]
H0 (HA1) 0.466 5.03 89.0
H1 (HB1) 0.466 5.06 276.0
H2 (HA2) 0.381 6.12 355.0
H3 (HB2) 0.361 4.92 222.0
H4 (HA3) 0.381 6.24 252.0
H5 (HB3) 0.361 4.92 135.0
Temperatures
TA1 [K] TA2 [K] TB1 [K] TB2 [K] Tp1 [K] Tp2 [K] Tc1 [K] Tc2 [K]
20.0 17.4 20.0 14.9 20.0 27.2 24.0 20.0 Edit  Delete
20.0 17.5 30.0 24.7 20.0 27.1 24.0 20.0 Edit  Delete
20.0 17.5 40.0 32.4 20.0 27.1 23.9 20.0 Edit  Delete
20.0 17.5 50.0 40.1 20.0 27.0 23.9 20.0 Edit  Delete

Reports

Noise temperatures
Method Tnoise [K] GQ1 [ADU/K] GU1 [ADU/K] GU2 [ADU/K] GQ2 [ADU/K] Details Report Action
non-linear fit 108.3±19.2 373±81 460±66 743±107 428±86 JSON Download Edit  Delete
Bandpasses
Spectrum
