STRIP70 – Y-factor test - repeated
General information
| Polarimeter | STRIP70 |
| Acquisition date | |
| Band | Q |
| Cryogenic? | Yes |
| Operators | Mario Zannoni |
| Description | Y-factor test - repeated |
| PHSW state | 1010 |
| Notes | The source data file was «SCI180430_091617 - STRIP_70_Y-Factor_LB__up_20-30-40-50K_PS1010_30Apr2018.txt» (1878 kB) |
| Author | f.benedini |
| Date of creation | |
| JSON record | Link |
- Download data file (376.4 KB)
HEMT biases
| HEMT | Vd [V] | Id [mA] | Vg [mV] |
|---|---|---|---|
| H0 (HA1) | 0.88 | 3.84 | 105.0 |
| H1 (HB1) | 0.91 | 5.58 | 124.0 |
| H2 (HA2) | 1.21 | 13.14 | 139.0 |
| H3 (HB2) | 1.2 | 19.23 | 277.0 |
| H4 (HA3) | 0.93 | 9.8 | 438.0 |
| H5 (HB3) | 0.92 | 13.34 | 320.0 |
Temperatures
| TA1 [K] | TA2 [K] | TB1 [K] | TB2 [K] | Tp1 [K] | Tp2 [K] | Tc1 [K] | Tc2 [K] | |
|---|---|---|---|---|---|---|---|---|
| 25.0 | 19.6 | 20.0 | 15.0 | 27.7 | 25.0 | 25.0 | 22.7 |
|
| 25.0 | 19.6 | 30.0 | 15.0 | 27.7 | 25.0 | 25.0 | 22.7 |
|
| 25.0 | 19.6 | 40.0 | 15.0 | 27.7 | 25.0 | 25.0 | 22.7 |
|
| 25.0 | 19.6 | 50.0 | 15.0 | 27.7 | 25.0 | 25.0 | 22.7 |
|
