STRIP61 – Bandpass characterization - PS 0110 - repeated

General information

Edit  Delete

Polarimeter STRIP61
Acquisition date
BandQ
Cryogenic?Yes
OperatorsFederica Benedini
DescriptionBandpass characterization - PS 0110 - repeated
PHSW state0110
Notes

The source data file was «SCI180504_123812 - STRIP61_Tcryo_RF-40dBm_0110__04May2018.txt» (459 kB)

Authorf.benedini
Date of creation
JSON recordLink
ADC offsets
PWR0 PWR1 PWR2 PWR3
1891 1866 1857 1783 Edit  Delete
Detector outputs
PWR0 PWR1 PWR2 PWR3
89170 89700 90160 91850 Edit  Delete
HEMT biases
HEMT Vd [V] Id [mA] Vg [mV]
H0 (HA1) 0.9 3.02 174.0
H1 (HB1) 0.9 3.06 337.0
H2 (HA2) 1.21 9.95 425.0
H3 (HB2) 1.2 12.0 510.0
H4 (HA3) 0.95 6.98 453.0
H5 (HB3) 0.92 8.07 173.0
Temperatures

Reports

Noise temperatures
Bandpasses
Method Central frequency Bandwidth Details Report Actions
43.15±0.16 7.52±0.73 JSON Download Edit  Delete
Spectrum
