STRIP37 – Bandpass characterization

General information

Edit  Delete

Polarimeter STRIP37
Acquisition date
BandQ
Cryogenic?Yes
OperatorsClaudio Pincella
PHSW state0101
Notes

The source data file was «SCI171205_112621 - STRIP37_Tcryo20K_RF_-40dBm_0101_V4_even-_H4-6mA__odd+_H5-9mA_05Dec2017.txt» (475 kB)

Authorclaudio
Date of creation
JSON recordLink
ADC offsets
PWR0 PWR1 PWR2 PWR3
1800 1820 1812 1819 Edit  Delete
Detector outputs
PWR0 PWR1 PWR2 PWR3
101200 99500 97150 100100 Edit  Delete
HEMT biases
HEMT Vd [V] Id [mA] Vg [mV]
H0 (HA1) 0.9 6.15 32.0
H1 (HB1) 0.9 8.0 51.0
H2 (HA2) 0.9 4.89 303.0
H3 (HB2) 0.9 7.06 418.0
H4 (HA3) 0.9 6.0 -141.0
H5 (HB3) 0.9 9.0 92.0
Temperatures

Reports

Noise temperatures
Bandpasses
Method Central frequency Bandwidth Details Report Actions
43.30±0.21 6.54±0.16 JSON Download Edit  Delete
Spectrum
