STRIP54 – Y-Factor test_up LB (PS0101-PWR0 blind) - Repeated
General information
| Polarimeter | STRIP54 |
| Acquisition date | |
| Band | Q |
| Cryogenic? | Yes |
| Operators | Federica Benedini |
| Description | Y-Factor test_up LB (PS0101-PWR0 blind) - Repeated |
| PHSW state | 0101 |
| Notes | The source data file was «SCI180507_074903 - STRIP54_Y-Factor_LB_up_20-30-40-50K_PS0101_07May2018.txt» (1497 kB) Polarimeter temperature set to 25K, to maintain control during Y-Factor tests. |
| Author | claudio |
| Date of creation | |
| JSON record | Link |
- Download data file (323.8 KB)
HEMT biases
| HEMT | Vd [V] | Id [mA] | Vg [mV] |
|---|---|---|---|
| H0 (HA1) | 0.9 | 3.25 | 0.0 |
| H1 (HB1) | 0.9 | 3.02 | 143.0 |
| H2 (HA2) | 1.2 | 13.9 | 193.0 |
| H3 (HB2) | 1.21 | 12.93 | 373.0 |
| H4 (HA3) | 0.91 | 9.1 | 393.0 |
| H5 (HB3) | 0.9 | 8.08 | 400.0 |
Temperatures
| TA1 [K] | TA2 [K] | TB1 [K] | TB2 [K] | Tp1 [K] | Tp2 [K] | Tc1 [K] | Tc2 [K] | |
|---|---|---|---|---|---|---|---|---|
| 20.0 | 17.4 | 20.0 | 13.6 | 27.8 | 25.0 | 25.0 | 22.1 |
|
| 20.0 | 17.4 | 30.0 | 18.2 | 27.8 | 25.0 | 25.0 | 22.1 |
|
| 20.0 | 17.4 | 40.0 | 27.2 | 27.8 | 25.0 | 25.0 | 22.1 |
|
| 20.0 | 17.4 | 50.0 | 31.9 | 27.8 | 25.0 | 25.0 | 22.1 |
|
