STRIP30 – Bandpass characterization - cryo - repeated - PS0110

General information

Edit  Delete

Polarimeter STRIP30
Acquisition date
BandQ
Cryogenic?Yes
OperatorsFederica Benedini
DescriptionBandpass characterization - cryo - repeated - PS0110
PHSW state0110
Notes

The source data file was «SCI180510_091509 - STRIP30_Tcryo_RF-40dBm_0110__10May2018.txt» (444 kB)

Authorclaudio
Date of creation
JSON recordLink
ADC offsets
PWR0 PWR1 PWR2 PWR3
1870 1807 1855 1868 Edit  Delete
Detector outputs
PWR0 PWR1 PWR2 PWR3
100950 102130 102930 98700 Edit  Delete
HEMT biases
HEMT Vd [V] Id [mA] Vg [mV]
H0 (HA1) 0.9 11.7 -180.0
H1 (HB1) 0.9 9.27 -107.0
H2 (HA2) 0.9 11.07 221.0
H3 (HB2) 0.9 11.05 324.0
H4 (HA3) 0.9 11.02 -98.0
H5 (HB3) 0.9 4.06 151.0
Temperatures
TA1 [K] TA2 [K] TB1 [K] TB2 [K] Tp1 [K] Tp2 [K] Tc1 [K] Tc2 [K]
20.0 19.0 20.0 13.3 25.1 22.5 22.6 20.0 Edit  Delete

Reports

Noise temperatures
Bandpasses
Method Central frequency Bandwidth Details Report Actions
43.54±0.35 6.87±0.21 JSON Download Edit  Delete
Spectrum
