STRIP84 – Y-factor test - PS 0101
General information
| Polarimeter | STRIP84 |
| Acquisition date | |
| Band | W |
| Cryogenic? | Yes |
| Operators | Federica Benedini, Claudio Pincella |
| Description | Y-factor test - PS 0101 |
| PHSW state | 0101 |
| Notes | The source data file was «SCI180521_124045 - STRIP_W97_Y-Factor_LB__up_20-30-40-50K_PS0101_21May2018.txt» (1486 kB) Very bad results |
| Author | f.benedini |
| Date of creation | |
| JSON record | Link |
- Download data file (317.4 KB)
HEMT biases
| HEMT | Vd [V] | Id [mA] | Vg [mV] |
|---|---|---|---|
| H0 (HA1) | 0.341 | 3.67 | 94.0 |
| H1 (HB1) | 0.502 | 5.15 | 281.0 |
| H2 (HA2) | 0.403 | 5.34 | 236.0 |
| H3 (HB2) | 0.343 | 3.65 | 292.0 |
| H4 (HA3) | 0.403 | 5.34 | 232.0 |
| H5 (HB3) | 0.343 | 3.65 | 140.0 |
Temperatures
| TA1 [K] | TA2 [K] | TB1 [K] | TB2 [K] | Tp1 [K] | Tp2 [K] | Tc1 [K] | Tc2 [K] | |
|---|---|---|---|---|---|---|---|---|
| 20.5 | 16.3 | 20.0 | 15.3 | 27.2 | 20.0 | 21.0 | 17.9 |
|
| 20.5 | 16.3 | 30.0 | 23.5 | 27.0 | 20.0 | 21.0 | 18.0 |
|
| 20.5 | 16.4 | 40.0 | 31.0 | 27.0 | 20.0 | 21.0 | 18.0 |
|
| 20.5 | 16.4 | 50.0 | 38.9 | 26.8 | 20.0 | 21.0 | 18.0 |
|
