Strip Test Database
STRIP71 – Long acquisition - pol JPL
General information
| Polarimeter | STRIP71 |
| Acquisition date | |
| Band | W |
| Cryogenic? | Yes |
| Operators | Federica Benedini |
| Description | Long acquisition - pol JPL |
| PHSW state | switching |
| Notes | The source data file was «SCI180523_110353 - STRIP_W23_1_f__PS-default_Polariz-US_2hours_23May2018.txt» (11498 kB) Cross-guide’s heater was disconnected, so it wasn’t possible to control TC2 or TC1. TC2 was disconnected too. In conclusion, no control on the cross-guide, but the test is considered to be fully valid. |
| Author | claudio |
| Date of creation | |
| JSON record | Link |
- Download data file (1.9 MB)
