STRIP72 – Bandpass characterization - PS 0101

General information

Edit  Delete

Polarimeter STRIP72
Acquisition date
BandW
Cryogenic?Yes
OperatorsFederica Benedini
DescriptionBandpass characterization - PS 0101
PHSW state0101
Notes

The source data file was «SCI180525_084947 - Wband25_Tcryo_RF-2dBm_PS0101_repeated_25May2018.txt» (868 kB)

Authorf.benedini
Date of creation
JSON recordLink
ADC offsets
PWR0 PWR1 PWR2 PWR3
1886 1913 1964 1888 Edit  Delete
Detector outputs
PWR0 PWR1 PWR2 PWR3
98200 94100 97500 97210 Edit  Delete
HEMT biases
HEMT Vd [V] Id [mA] Vg [mV]
H0 (HA1) 0.5 4.86 413.0
H1 (HB1) 0.5 3.4 376.0
H2 (HA2) 0.44 5.44 342.0
H3 (HB2) 0.4 5.88 356.0
H4 (HA3) 0.44 5.44 342.0
H5 (HB3) 0.4 5.88 356.0
Temperatures
TA1 [K] TA2 [K] TB1 [K] TB2 [K] Tp1 [K] Tp2 [K] Tc1 [K] Tc2 [K]
20.0 19.7 20.0 15.4 24.0 19.7 20.0 17.3 Edit  Delete

Reports

Noise temperatures
Bandpasses
Method Central frequency Bandwidth Details Report Actions
96.07±0.16 7.02±0.56 JSON Download Edit  Delete
Spectrum
