STRIP74 – Long acquisition

General information

Edit  Delete

Polarimeter STRIP74
Acquisition date
BandW
Cryogenic?Yes
OperatorsFederica Benedini, Claudio Pincella
PHSW stateswitching
Notes

The source data file was «SCI180528_150940 - STRIP_W36_1_f__PS-default_Polariz-US_12hours_28May2018.txt» (72294 kB)

Authorfincardona
Date of creation
JSON recordLink
ADC offsets
PWR0 PWR1 PWR2 PWR3
2017 2064 2003 1969 Edit  Delete
Detector outputs
PWR0 PWR1 PWR2 PWR3
98170 98470 97160 98900 Edit  Delete
HEMT biases
HEMT Vd [V] Id [mA] Vg [mV]
H0 (HA1) 0.185 3.0 291.0
H1 (HB1) 0.213 3.4 309.0
H2 (HA2) 0.348 7.25 581.0
H3 (HB2) 0.371 6.9 730.0
H4 (HA3) 0.348 7.25 581.0
H5 (HB3) 0.371 6.9 730.0
Temperatures
TA1 [K] TA2 [K] TB1 [K] TB2 [K] Tp1 [K] Tp2 [K] Tc1 [K] Tc2 [K]
20.0 19.5 20.0 15.2 24.0 13.6 20.0 17.5 Edit  Delete

Reports

Noise temperatures
Bandpasses
Spectrum
Method αI αQ fkQ [mHz] WNQ [mK2/Hz] αU fkU [mHz] WNU [mK2/Hz] Details Report Actions
0.61843±0.00000 1.028±0.000 3000.0±700.0 13.00±3.000 0.975±0.000 8000.0±2400.0 6.00±2.000 JSON Download Edit  Delete
