STRIP64 – Bandpass characterization (PWR0 blind)

General information

Edit  Delete

Polarimeter STRIP64
Acquisition date
BandQ
Cryogenic?Yes
OperatorsFederico Incardona
DescriptionBandpass characterization (PWR0 blind)
PHSW state0110
Notes

The source data file was «SCI170727_113617 - STRIP64_Tcryo20K_RF_-40dBm_0110_27Jul2017_1.txt» (417 kB)

Authorfincardona
Date of creation
JSON recordLink
ADC offsets
PWR0 PWR1 PWR2 PWR3
1894 1879 1904 2053 Edit  Delete
Detector outputs
HEMT biases
HEMT Vd [V] Id [mA] Vg [mV]
H0 (HA1) 0.91 2.96 430.0
H1 (HB1) 0.91 3.15 503.0
H2 (HA2) 1.21 11.73 42.0
H3 (HB2) 1.21 11.0 119.0
H4 (HA3) 0.91 3.04 315.0
H5 (HB3) 0.91 7.01 320.0
Temperatures

Reports

Noise temperatures
Bandpasses
Method Central frequency Bandwidth Details Report Actions
43.24±0.13 7.73±0.39 JSON Download Edit  Delete
Spectrum
