STRIP48 – Y-factor test, warm up (PWR3 blind)
General information
| Polarimeter | STRIP48 |
| Acquisition date | |
| Band | Q |
| Cryogenic? | Yes |
| Operators | Paola Battaglia, Claudio Pincella, Mario Zannoni |
| Description | Y-factor test, warm up (PWR3 blind) |
| PHSW state | 1001 |
| Notes | The source data file was «SCI170504_122940 - STRIP48_Y-Factor_LB_20K_up_20-30-40_PS1001_MC5_04May2017.txt» (1016 kB) |
| Author | paola |
| Date of creation | |
| JSON record | Link |
- Download data file (175.7 KB)
HEMT biases
| HEMT | Vd [V] | Id [mA] | Vg [mV] |
|---|---|---|---|
| H0 (HA1) | 0.72 | 2.13 | 57.0 |
| H1 (HB1) | 0.9 | 5.3 | -13.0 |
| H2 (HA2) | 0.75 | 3.54 | 254.0 |
| H3 (HB2) | 0.75 | 3.47 | 277.0 |
| H4 (HA3) | 0.9 | 2.6 | -35.0 |
| H5 (HB3) | 0.75 | 1.62 | 133.0 |
Temperatures
| TA1 [K] | TA2 [K] | TB1 [K] | TB2 [K] | Tp1 [K] | Tp2 [K] | Tc1 [K] | Tc2 [K] | |
|---|---|---|---|---|---|---|---|---|
| 20.0 | 24.9 | 20.0 | 22.8 | 20.0 | 13.7 | 15.0 | 24.9 |
|
| 20.0 | 24.9 | 30.0 | 31.4 | 20.0 | 13.7 | 15.0 | 24.9 |
|
| 20.0 | 24.9 | 40.0 | 41.5 | 20.0 | 13.7 | 15.0 | 24.9 |
|
