STRIP55 – Y-factor test, warm up (PWR3 blind)
General information
| Polarimeter | STRIP55 |
| Acquisition date | |
| Band | Q |
| Cryogenic? | Yes |
| Operators | Claudio Pincella |
| Description | Y-factor test, warm up (PWR3 blind) |
| PHSW state | 0110 |
| Notes | The source data file was «SCI170516_102917 - STRIP54_Y-Factor_LB_20K_up_20-30-40_PS0110_16May2017.txt» (957 kB) |
| Author | paola |
| Date of creation | |
| JSON record | Link |
- Download data file (188.7 KB)
HEMT biases
| HEMT | Vd [V] | Id [mA] | Vg [mV] |
|---|---|---|---|
| H0 (HA1) | 0.9 | 4.5 | 20.0 |
| H1 (HB1) | 0.9 | 5.0 | 56.0 |
| H2 (HA2) | 1.2 | 16.9 | -192.0 |
| H3 (HB2) | 1.22 | 17.0 | -225.0 |
| H4 (HA3) | 0.91 | 11.0 | 396.0 |
| H5 (HB3) | 0.93 | 12.0 | 418.0 |
Temperatures
| TA1 [K] | TA2 [K] | TB1 [K] | TB2 [K] | Tp1 [K] | Tp2 [K] | Tc1 [K] | Tc2 [K] | |
|---|---|---|---|---|---|---|---|---|
| 20.0 | 19.5 | 20.0 | 20.2 | 20.0 | 13.7 | 15.2 | 17.3 |
|
| 20.0 | 19.5 | 30.0 | 30.2 | 20.0 | 13.7 | 15.3 | 17.6 |
|
| 20.0 | 19.4 | 40.0 | 40.0 | 20.0 | 13.7 | 15.5 | 17.7 |
|
